STEELDECK & SLIP-FREE
|
STEELDECK - An Environmentally Sound,
Lifetime Surface for Your Dock.
More specs and features | Diagrams and panel dimensions
|
 STEELDECK's patent pending design delivers an ultra strong, environmentally-friendly decking surface with a life expectancy of up
to 50 years that requires near zero maintenance under even the
toughest fresh and saltwater conditions.
Designed For Durability, Safety And Comfort
At the core of STEELDECK is 14-gauge virgin steel combined with 35% recycled steel. On its surface is a field-proven weather resistant PVC coating that is textured to provide an all-season slip resistant deck.
Additionally, STEELDECK panels are perforated for fast run off of surface water, snow and ice; to dissipate lift pressure from storms and turbulent water action; and provide light penetration from above. And the insulating properties of the PVC coating leave the surface cool to bare feet even in the heat of the Arizona sun.
 Unmatched Panel Strength With Flexible Panel Sizes
STEELDECK panels accommodate stringers spans of 24" to 48" on center while supporting up to 2915 lbs per square foot. Where building codes allow, new dock construction cost may be reduced significantly with these greater spans.
With seven standard rectangular panel sizes ranging from 24" x 48" to 48" x 72",and a 45 degree corner, STEELDECK panels make your decking projects fast and easy. Panels can be cut with conventional tools to fit around pilings and roof supports. Exposed steel is simply re-coated using a patch tube of the same PVC product that air dries quickly to form a complete waterproof seal.
STEELDECK Is An Environmentally-Friendly, Cost Saving Solution For Your Docks
The expected life of a STEELDECK panel is 40 to 50 years. This far exceeds the 15 year life expectancy, or less, of other decking
materials that will need to be replaced two or three times during STEELDECK's lifetime. And ongoing maintenance on STEELDECK is near-zero. So STEELDECK not only protects you against the cost of multiple re-decking projects and regular maintenance costs, but it also saves on landfill and recycling charges common with other decking types. A marina or dock system with STEELDECK is truly a "clean marina."
 Panels Install 6X Faster Than Other Decking
A STEELDECK can be installed typically in 1/6 the time of traditional
decking materials and without the waste common from cutting wood and composite decking.
Panels can be attached to dock frames through pre-drilled mounting holes with as few as four TEK screws on steel or aluminum frames. With some dock frames and building code compliance panels may be laid in place without fasteners. In either case panels can be removed or lifted easily for access to under dock utility runs.
Panels can also be cut to fit around pilings, roof supports and other
obstructions. Any exposed steel edges can then be coated using the PVC vinyl patch kit that comes with your STEELDECK shipment.
And with panel widths of 2', 3' and 4' and panel lengths of 4', 5' and 6', you'll be surprised with how fast your new deck can be installed.
 STEELDECK Can Add Strength to New or Old Dock Frames
Whether you are resurfacing existing dock frames or new frames, STEELDECK can become a structural member of your dock system when fastened to your frames at all points of connection that are provided in the STEELDECK panel.
Field-Tested PVC Coating and Perforations Provide Safe Surface
Actually it's better than that! STEELDECK's slip-resistant PVC coating is KID-tested. This is the same PVC material and coating process that has been used on commercial-grade playground equipment for over 20 years. No better test than a couple hundred kids at recess every day. STEELDECK is also perforated for fast run-off of surface water, snow and ice; and to minimize the lifting effects of wave splashes and surges from under the dock. And the perforations let light penetrate to the vegetation and aquatic life residing under the dock.
 Slip-Free panels are custom fabricated to fit your ramps with a clear span of up to six (6) feet. Each panel is a perforated steel, aluminum or stainless covered with a hot-dip vinyl coating on all sides. Mineral granules are imbedded in the surface vinyl to provide a non-skid coating that is aggressive but tender to bare feet.
Easy to Install and Easy Access to Utilities Post Install
Under dock utilities can be difficult to access and time consuming with some decking products. STEELDECK panels can be lifted easily to expose a larger area under the decking for any utility work needed.
Panel Cutting
Panels are easy to cut to fit around pilings, power pedestals, roof supports and other walkway obstructions. Vinyl patch can be applied to freshly cut edges to seal them against weather and water.
Price Request
Please contact us by using the information below.
|
|
|
Scottco Distributors, Inc.
Phone: (208) 762-2719
Toll-Free: (800) 932-9414
Fax: (208) 772-6353
E-Mail: info@scottcomarine.com
|
